MORE+NEW PRODUCTS

  • EG070WY040-F01

    EG070WY040-F01

    1. Model No: EG070WY040-F01

      Resolution: 800*480

      Outline Dimension: 164.9*100*3.4mm

      LCD Active Area(mm): 151.68*85.92mm

      Interface: RGB 24 BITS

      Viewing Angle: 12 O’ clock

      Driving IC: \

      Display Mode: Normally White,Transmissive

      Technology Type: a-Si TFT active matrix

      Surface treatment: Anti-Glare

      Pixel Pitch (mm): \

      Pixel Configuration: R.G.B. Stripe

      FPC type: ZIP

      Operating Temperature: -20 to +70℃

      Storage Temperature: -30 to +80℃

      Brightness: 200Cd/m2

      Warranty:12 months


    View details >>

  • EG050WG050-F01

    EG050WG050-F01

    1. Model No:EG050WG050-F01

      Resolution:800RGB*480DOTS

      Outline Dimension:120.7*76.3*3.07

      LCD Active Area(mm):108*64.8

      Interface:RGB 24 BITS

      Viewing Angle:6 O’ clock

      LED Numbers:6*2LED

      LED life:30000h

      Display Mode:Normally White,Transmissive

      Technology Type:a-Si TFT active matrix

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      Operating Temperature: -20 to +70℃

      Storage Temperature: -30 to +80℃

      Color Depth: 262K

      Brightness:450Cd/m2

      Warranty:12 months


    View details >>

  • EG050WY040-F01

    EG050WY040-F01

    1. Model No:EG050WY040-F01

      Resolution:480RGB*272DOTS

      Outline Dimension:120.7*75.2*4.2

      LCD Active Area(mm):110.88*62.832

      Interface:RGB24 BIT

      Viewing Angle:6 O’ clock

      LED Numbers:5*2LED

      LED life:30000h

      Display Mode:Normally White,Transmissive

      Technology Type:a-Si TFT active matrix

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      Operating Temperature: -20 to +70℃

      Storage Temperature: -30 to +80℃

      Color Depth: 262K

      Brightness:250Cd/m2

      Warranty:12 months


    View details >>

  • EG043WGA45-F01

    EG043WGA45-F01

    1. Model No:EG043WGA45-F01

      Resolution:480RGB*800DOTS

      Outline Dimension:114.6(H)*70.6(W)*3.4(T) (Exclude FPC)

      LCD Active Area(mm):93.6(H)*56.16(W)

      Interface:24-Bit Parallel RGB

      Viewing Angle:full viewing angle

      LED Numbers:White LED*10

      LED life:20000h

      Display Mode:Normally White,Transmissive

      Technology Type:a-Si TFT active matrix

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      FPC type:Connector type

      Operating Temperature: -20 to +70℃

      Storage Temperature: -30 to +80℃

      Color Depth: 262K

      Brightness:280Cd/m2

      Warranty:12 months


    View details >>

  • EG043WG040-F01

    EG043WG040-F01

    1. Model No:EG043WG040-F01

      Resolution:480RGB*272DOTS

      Outline Dimension:67.15(H)*105.4(W)*2.95 (T)(Exclude FPC)

      LCD Active Area(mm):53.86(H)*95.04(W)

      Interface:24-Bit Parallel RGB / 8-Bit Seirial RGB

      Viewing Angle:12 o’ clock

      LED Numbers:White LED*7

      LED life:50000h

      Display Mode:Normally White,Transmissive

      Technology Type:a-Si TFT active matrix

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      Operating Temperature: -10 to +60℃

      Storage Temperature: -20 to +70℃

      Color Depth: 262K

      Brightness:350 Cd/m²

      Warranty:12 months


    View details >>

  • EG035WY050-F01

    EG035WY050-F01

    1. Model No:EG035WY050-F01

      Resolution:320RGB*240DOTS

      Outline Dimension:63.9(H)*76.9(W)*3.3(T)(Exclude FPC)

      LCD Active Area(mm):52.56(H)*70.08(W)

      Interface:24-Bit Parallel RGB / 8-Bit Seirial RGB

      Viewing Angle:12 o’ clock

      LED Numbers:White LED*6

      LED life:30000h

      Display Mode:Normally White,Transmissive

      Technology Type:a-Si TFT active matrix

      Pixel Pitch (mm):0.198(H) x 0.198(V)

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      FPC type:ZIP

      Operating Temperature: -10 to +60℃

      Storage Temperature: -20 to +70℃

      Color Depth: 262K

      Brightness:250Cd/m2

      Warranty:12 months


    View details >>

  • EG028TF050-F01

    EG028TF050-F01

    1. Model No:EG028TF050-F01

      Resolution:240RGB*320DOTS

      Outline Dimension:50.0(W)×69.2(H)×3.6(T)

      LCD Active Area(mm):43.2(W)×57.6(H)

      Interface:4-lines_8bit / 3-lines_9bit SPI, 8-/ 9-/16-/18-bit 8080-series system interface, 6-/16-/18-bit RGB interface

      Viewing Angle:12 o’ clock

      LED Numbers:4 White LED In Parallel

      LED life:30000h

      Display Mode:Normally White,Transmissive

      Technology Type:a-Si TFT active matrix

      Pixel Pitch (mm):0.198(H) x 0.198(V)

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      FPC type:Solder type

      Operating Temperature: -20 to +70℃

      Storage Temperature: -30 to +80℃

      Color Depth: 262K

      Brightness:200Cd/m2

      Warranty:12 months


    View details >>

  • EG024MTA40-F03

    EG024MTA40-F03

    1. Model No:EG024MTA40-F03

      Resolution:240*320

      Outline Dimension:42.72*60.26*3.25

      LCD Active Area(mm):36.72*48.96

      Interface:SPI/RGB/MCU

      Viewing Angle: Free viewing angle

      LED Numbers:White LED*4

      LED life:50000h

      Display Mode:Normally Black

      Technology Type:a-Si TFT active matrix

      Pixel Pitch (mm):0.153(H) x 0.153(V)

      Pixel Configuration:R.G.B. Stripe

      Surface treatment:Anti-Glare

      FPC type:ZIP type

      Operating Temperature: -20 to +70℃

      Storage Temperature: -30 to +80℃

      Color Depth: 262K

      Brightness:250Cd/m2

      Warranty:12 months



    View details >>
